MINE POLE

The simplest form of timber elongate.
Available in various sizes to suit customer requirements.
• 16 – 18 Poles
• 18 – 20 Poles
• 19 – 21 Poles
• 19 – 23 Poles

TERRAMAC POLE

The Terramac is an unturned mine pole with a machined end for the 140 or 160 diameter prestressing unit to be fitted onto. This means cost saving by using a smaller pre-stress unit.
•16 – 18cm Terramac Poles
•18 – 23cm Terramac Poles
•19 – 22cm Terramac Poles

PENCIL PROP

The simplest yielding support available in either un-turned or turned format. Pencil Props are available in various diameters and lengths, and are good for limited closure of 150mm.
•16 – 18 Pencil
•17 – 19 Pencil
•18 – 20 Pencil
•19 – 21 Pencil

PROFILE PROP

Available diameters are 16-18cm & 18-20cm. Lengths are 0.8-3m. Pre-Stress to 200kN. Load bearing 300kN. Yielding capability 250-300mm. Blast-on timber prop up to 1m from face. Cost effective and user friendly.
•16 – 18cm Profile
•18 – 20cm Profile
•18cm Profile (Turned)
•20cm Profile (Turned)

SQUARE PROP

The Square Prop consists of a timber elongate supplied with a pre-stressing device. The timber section of the prop is cut in a specific way to promote yielding. The prop is designed specifically for a deformation range up to 300mm.
•16 – 18cm Square Prop
•18 – 20cm Square Prop
•20cm Square Prop

WEDGE PROP

Wedge Props are turned for a more consistent yielding elongate. Supplied with a fitted PSU, they can be easily pre-stressed underground using conventional pumping systems, and are good for 400mm yield.
•18cm Wedge prop
•20cm Wedge prop

NIMRITE®

NimRite® Prop is a pre-stress-able elongate support designed specifically to withstand large closure without buckling under yield. Various diameters, yield loads, and deformation ranges are available to suit customer requirements.
•NimRite® Horizontal (HC)
•NimRite® Vertical (VC)

CLUSTERS

Including a number of elongate supports strapped together to form a very stiff timber structure, designed for use in low closure applications where quick and easy installation is the order of the day.
•Mine pole Cluster
•Pencil Cluster
•Profile Cluster
•Terramac Cluster
•Wedgeprop Cluster
